GE DS200TCQAG1A Analog I/O Board

Description

The DS200TCQAG1A module processes various analog signals, including LVDT inputs, servo valve outputs, thermocouple inputs, 4-20 mA signals, vibration inputs, and relay driver outputs. It ensures accurate signal conditioning for critical turbine control applications.

Specifications

• Signal Types:

  • LVDT/LVDR position inputs.

  • Thermocouple inputs with cold junction compensation.

  • 4-20 mA inputs and outputs.

  • Vibration and pulse inputs.

  • Generator and line signals.

• Connectors:

  • JA, JB, JD, JE, JF, JG for signal exchange.

  • 2PL for power distribution.

  • 3PL for data bus communication

Features

• Signal Conditioning: Scales and conditions analog signals for accurate processing.

• Versatile Connectivity: Supports multiple signal types and interfaces.

• Robust Design: Built to withstand demanding industrial conditions.

• Ease of Integration: Compatible with GE Speedtronic Mark V systems.

• Self-Diagnostics: Monitors system health for reliable operation.
