V18345-1027521001 | ABB | TZIDC Electro-Pneumatic Positioner

Key Features

• Case / Mounting:

• Aluminum housing, electrostatic varnish, IP65 / NEMA 4X protection

• For linear actuators per DIN/IEC 534 / NAMUR or rotary actuators per VDI/VDE 3845

• Ready for integral mounting

• Type:

• Electro-Pneumatic Positioner TZIDC, intelligent and configurable

• With indicator and operator panel

• Input / Communication Port:

• 4…20 mA two-wire input with connector plug for LKS adapter

• FSK module for HART communication

• Explosion Protection:

• ATEX Ex II 2 G EEx ia II C T6

• Output / Safe Position:

• Double-acting, fail freeze in case of electrical power failure

• Connections:

• Cable: Thread 1/2-14 NPT

• Air pipe: Thread 1/4-18 NPT

• Feedback Modules:

• Option for analog or digital position feedback: without

• Optional mechanical kit for digital position feedback with proximity switches SJ2-SN (NC or logical 1)

Technical Data

• Output Signal (two-wire): 4 … 20 mA nominal range

• Digital Input:

• 0 … 5 V DC logical “0”

• 11 … 30 V DC logical “1”

• Digital Output (DIN 19234/NAMUR): Supply voltage 5 … 11 V DC

• Supply Pressure: 1.4 … 6 bar (20 … 90 psi)

• Air Consumption: < 0.03 kg/h / 0.015 scfm (independent of supply pressure)

Housing & Finish

• Material / Protection: Aluminum, IP65 / NEMA 4X

• Surface / Color: Electrostatic epoxy varnish, stove-hardened; case black RAL 9005 matte; housing cover Pantone 420

• Pneumatic Connections: Threads G 1/4 or 1/4-18 NPT

Dimensions & Weight

• Weight: 1.7 kg

• Shipping Weight: 3 kg
