3300 Series Monitor System

The Bently Nevada 3300 Series Monitoring System was highly configurable, offering a variety of modules and options for monitoring various parameters in industrial applications.

3300/05 Rack:

• The rack houses all 3300 modules and is available in sizes ranging from 4 to 14 slots.

3300 Modules and Monitors:

1. 3300/01 Rack Interface Module
2. 3300/03 Rack Interface Module
3. 3300/15 Dual Vibration Monitor
4. 3300/16 XY/GAP Dual Vibration Monitor
5. 3300/20 Dual Thrust Position Monitor
6. 3300/25 Dual Acceleration Monitor
7. 3300/26 Dual Acceleration RMS Monitor
8. 3300/30 TC Monitor
9. 3300/35 RTD Monitor
10. 3300/40 Eccentricity Monitor
11. 3300/45 Dual Differential Expansion Monitor
12. 3300/46 Ramp Differential Expansion Monitor
13. 3300/47 Complementary Input Differential Expansion Monitor
14. 3300/48 Case Expansion Monitor
15. 3300/55 Dual Velocity Monitor
16. 3300/61 Dual Vector Monitor
17. 3300/65 Dual Probe Monitor
18. 3300/70 Dual Valve Position Indicator

3300 Power Supplies:

• 3300/12 AC Power Supply (replaced the 3300/10 AC Power Supply)
• 3300/14 DC Power Supply

Documents

Spec Sheets:

• Bently Nevada 3300/05 Rack Datasheet PDF (200 KB)
• Bently Nevada 3300 Relay Modules Datasheet PDF (232 KB)
• Bently Nevada 3300 Series Power Supplies Datasheet PDF (458 KB)

Manuals:

• Bently Nevada 3300 Series Monitoring System Manual PDF (322 KB)

This arrangement should make it easier to understand the components and options available in the Bently Nevada 3300 Series Monitoring System.
