900B08-0001 | Honeywell | 8 Channel Analog Output Module

Description

The Honeywell 900B08-0001 is an 8-channel analog output module designed for the ControlEdge HC900 distributed control system. It delivers precise analog signals to actuators, valves, and other field devices, enabling accurate and responsive control in industrial automation environments.

Specifications

• Model Number: 900B08-0001

• Module Type: Analog Output

• Number of Channels: 8

• Output Signal Range: Typically 4–20 mA (configurable)

• Resolution: 12-bit or higher

• Accuracy: ±0.1% of full scale

• Load Impedance: 0 to 600 ohms

• Response Time: <1 ms per channel

• Isolation: Channel-to-channel and channel-to-ground

• Power Supply: 24 VDC

• Power Consumption: Up to 5 W

• Operating Temperature: -20°C to +60°C

• Storage Temperature: -40°C to +85°C

• Humidity Range: 5% to 95% non-condensing

• Dimensions: Approx. 31.3 cm × 27.8 cm × 3 cm

• Weight: 0.56 kg

Features

• Multi-Channel Output: Controls up to eight devices from a single module

• High Precision: Ensures accurate signal delivery for critical process control

• Robust Isolation: Protects against electrical noise and cross-channel interference

• Fast Response: Ideal for dynamic applications requiring rapid signal updates

• Modular Integration: Seamlessly fits into Honeywell HC900 systems

• Versatile Applications: Suitable for motor control, valve positioning, and actuator management

• Compact Design: Saves space in control cabinets

• Reliable Performance: Built for demanding industrial environments
