InquiryABB 3BHE023126R0020 AF D242 A20 CCP Converter Control Panel
Configured for converter control and interface functions within ABB drive and power conversion systems, the ABB 3BHE023126R0020 (AF D242 A20 CCP Converter Control Panel) provides the physical control panel infrastructure for converter-related control architectures. The unit is supplied as a factory-assembled control panel component for integration into ABB system environments.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 3BHE023126R0020 |
| Brand | ABB |
| Product Type | CCP Converter Control Panel |
| Description | AF D242 A20: CCP Converter Control Panel |
| Origin | Switzerland, China |
| Part Type | New |
| Mounting Type | Control Panel Assembly |
| Product Net Length | 135 mm |
| Product Net Width | 125 mm |
| Product Net Height | 120 mm |
Converter Control System Integration
The AF D242 A20 is designed as part of an ABB converter control infrastructure. The panel serves as a hardware interface element within converter systems, supporting installation and integration of control-related functions associated with power conversion applications.
Control Panel Architecture
Within ABB converter platforms, control panels provide mechanical and electrical interfaces between system control equipment and associated field connections. Proper integration with the designated converter system is required to ensure compatibility with installed hardware and firmware configurations.
Frequently Asked Questions
Q: Is the AF D242 A20 supplied as a standalone controller?
A: The available catalog information identifies the unit as a CCP Converter Control Panel rather than a standalone controller module.
Q: Are power requirements specified for this model?
A: No specific supply voltage or power consumption data is provided in the available documentation.
Q: Is the product intended for cabinet integration?
A: Yes. The unit is supplied as a converter control panel assembly for installation within a compatible system configuration.
Field Installation Guidelines
-
Verify compatibility with the designated ABB converter platform before installation.
-
Ensure adequate cabinet space according to the published dimensions.
-
Follow applicable grounding and shielding practices for control wiring.
-
Separate control cables from high-power conductors where possible.
-
Inspect all connections and mounting hardware before energizing the system.
-
