Bently Nevada 133835-02 3500/61 TC Isolated I/O Module Internal Terminations

Description:

The 133835-02 module, part of Bently Nevada’s series of isolated I/O modules, provides reliable temperature measurement and control using thermocouple (TC) inputs. It is designed to ensure accurate readings and robust performance in various industrial applications.

Specifications:

• Input Channels: 4 isolated channels
• Input Type: Thermocouple (TC)
• Temperature Range: -270°C to +1372°C
• Accuracy: ±0.1% of full scale
• Isolation Voltage: 1500V DC (channel-to-channel and channel-to-ground)
• Power Supply: 24V DC (nominal), 18V to 32V DC (range)
• Power Consumption: 5W max
• Dimensions: 241.3 mm x 24.4 mm x 163.1 mm (9.50 in x 0.96 in x 6.42 in)
• Operating Temperature: -20°C to +60°C
• Storage Temperature: -40°C to +85°C
• Humidity: 0% to 95% RH (non-condensing)
• Weight: 0.46 kg (1.01 lbs)
• Resolution: 16-bit
• Sampling Rate: Up to 10 samples per second per channel
• Input Impedance: >10 MΩ
• Common Mode Rejection Ratio (CMRR): 120 dB
• Linearity: ±0.01% of full scale
• Communication Interface: Modbus TCP/IP, RS-485

Features:

• Temperature Monitoring: Supports multiple thermocouple inputs for precise temperature measurement.
• Isolation: High isolation voltage provides reliable operation in industrial settings.
• Versatility: Accommodates a wide temperature range and different thermocouples, suitable for various industrial applications.
• Durability: Designed to endure harsh industrial conditions with robust construction.
