Bently Nevada 330101-00-08-10-01-00 3300 XL 8 mm Proximity Probe

The Bently Nevada 330101-00-08-10-01-00, also cataloged as the 330101 3300 XL 8 mm Proximity Probe, operates as a dedicated hardware component for non-contact shaft displacement measurement within Bently Nevada proximity transducer systems. The probe generates an eddy-current sensing field to detect shaft position and vibration, providing the primary measurement element for rotor dynamic monitoring and machinery protection applications.

Suffix Breakdown & Model Matrix

The supplied documentation identifies the following configuration elements within the 330101-00-08-10-01-00 ordering structure.

• 330101 designates the 3300 XL 8 mm Proximity Probe product family.

• 00 specifies an unthreaded length of 0.0 in.

• 08 specifies an overall case length of 0.8 in.

• 10 identifies a 1.0 m total probe length (3.3 ft).

• 01 specifies a Miniature Coaxial ClickLoc connector with connector protector and standard cable.

• 00 indicates that agency approval is not required.

Hardware Specifications

Eddy-Current Probe Scaling and Gap Voltage Validation

The 3300 XL 8 mm probe serves as the sensing element within a complete proximity transducer system consisting of a probe, extension cable, and Proximitor sensor. The probe measures dynamic shaft vibration and static shaft position through eddy-current interaction with a conductive target surface. During installation and commissioning, probe system scaling is verified through gap voltage measurements. For properly calibrated Bently Nevada proximity systems, nominal operating targets near -10 VDC are commonly used to verify that the probe is positioned within its linear measurement region. Maintaining proper gap voltage contributes to accurate rotor dynamic analysis and vibration monitoring performance.

Frequently Asked Questions

Q: Can the 330101-00-08-10-01-00 operate independently without a Proximitor sensor?
A: No. The probe is intended to operate as part of a complete Bently Nevada proximity transducer system that includes a compatible extension cable and Proximitor sensor.

Q: What machinery applications is the probe intended for?
A: The probe is designed for dynamic shaft vibration measurement and static shaft position monitoring on fluid-film bearing machinery.

Q: What connector configuration is provided?
A: The model includes a Miniature Coaxial ClickLoc connector with connector protector and standard cable assembly.

Field Installation Guidelines

• Verify compatibility between the probe, extension cable, and Proximitor sensor before installation.

• Ensure the target material and geometry conform to transducer system requirements.

• Route probe cables separately from motor feeders, switching circuits, and high-energy conductors.

• Avoid excessive cable bending, crushing, or tensile loading during installation.

• Secure the ClickLoc connector fully to maintain signal integrity.

• Confirm probe mounting rigidity to prevent structural vibration effects on measurements.

• Validate transducer gap voltage prior to placing the measurement channel into service.

• Inspect cable routing periodically for abrasion, contamination, or mechanical damage.
