GE DS200TCTLG1A Steam Turbine Reheat Board
The GE DS200TCTLG1A is a steam turbine reheat board, part of the Mark V series used in turbine control systems. Below are the key technical specifications:
Technical Specifications
-
Part Number: DS200TCTLG1A
-
Series: Mark V
-
Dimensions: 13.50 x 9.00 x 2.00 inches
-
Weight: 1.80 lbs
-
Functional Description: Steam Turbine Trip Board
Primary Components
- Primary trip relays (PTR1 & 2)
- Emergency trip relays (ETR1 & 2)
Auxiliary Control Outputs
- Oil test solenoid
- Mechanical lockout solenoid
- Oil reset solenoid valve
- Electrical lockout solenoid
Features
- Designed for steam turbine control systems
- Equipped with primary and emergency trip relays for enhanced safety
- Provides multiple auxiliary control outputs for comprehensive functionality
Applications
- Steam turbine reheat and trip control
- Power plant automation
- Industrial process control in energy generation
