GE IC200UDD220 VersaMax Micro PLC Module

Description

GE IC200UDD220 is a VersaMax Micro PLC module featuring 22 digital inputs and 8 digital outputs. It’s designed for compact industrial control applications requiring reliable I/O processing, high-speed counters, and flexible communication options.

Specifications

• Model: IC200UDD220

• Input Channels: 22 digital inputs (24VDC)

• Output Channels: 8 NPN transistor outputs (sink type)

• Power Supply: 24VDC nominal (range: 19.2VDC to 30VDC)

• Communication Ports: 1 RS-232 serial port + 1 optional port

• High-Speed Counters: Supports up to 4 HSC inputs

• Memory: Non-volatile flash for program and firmware

• Dimensions: 150 mm × 75 mm × 100 mm

• Weight: Approx. 300 g

• Operating Temperature: –20°C to +60°C

• Storage Temperature: –40°C to +85°C

• Isolation Voltage: 1500V RMS (field-to-logic)

• Protection Rating: IP20

• Software Requirement: Machine Edition 5.7 or higher

• Battery Backup: Requires IC200ACC414 for data retention

Features

• Compact Design: Ideal for space-constrained control panels

• Flexible I/O Configuration: Supports both standard and high-speed inputs

• PWM Output Capability: Select outputs can function as pulse-width modulated signals

• Diagnostic LEDs: Indicators for module status and fault conditions

• Time-of-Day Clock: Built-in for scheduling and timestamping

• Expansion Support: Connects up to 4 additional modules

• User-Friendly Programming: Online logic editing without controller shutdown

• Protective Terminal Strips: Removable with covers for safe wiring

• Industrial Reliability: Built for harsh environments and long-term operation
