GE IS420ESWBH2A Ethernet IONet Switch

Description

IS420ESWBH2A is anEthernet IONet Switch manufactured by General Electric, designed as part of the Mark VIe Series for use in gas turbine control systems. All IONet switches used in Mark VIe and Mark VIeS Safety control systems are from GE’s product line of industrial, unmanaged Ethernet 10/100 switches, specifically engineered to meet the requirements of real-time industrial control applications.

Specifications

• Part Number: IS420ESWBH2A

• Manufacturer: General Electric

• Series: Mark VIe

• Product Type: Ethernet IONet Switch

• Country of Origin: USA

Characteristics

• Standards Compliance: IEEE 802.3, 802.3u, and 802.3x

• Connectivity: 10/100 Base-T copper with auto-negotiation

• Duplex Mode: Full/Half-duplex auto-negotiation

• Uplink: 100 Mbps FX uplink port

• Auto-Sensing: HP-MDIX auto-sensing

• LED Indicators:

• Link Presence, Activity, Duplex, and Speed per port (dual-color LEDs)

• Power status LED

• Buffer & MAC: Minimum 256 KB buffer with 4K MAC addresses

• Power Redundancy: Diode-OR’d redundant power supply inputs

Features

• Number of Ports: 16 ports, 10/100Base-TX copper, RJ-45

• Power Requirements: 24 / 28 V DC, 1 A max

• Power Supply Connector: Phoenix Contact (MC 1.5/S-STF-3.81)

• Dimensions (H × W × D): 18.8 × 8.6 × 5.6 cm (7.40 × 3.40 × 2.20 in)

• Operating Temperature: –40 to +70 °C (–40 to +158 °F)

• Storage Temperature: –40 to +85 °C (–40 to +185 °F)

• Mounting: DIN-rail (requires separately purchased mounting clip)
