Honeywell CC-PAON01 Analog Output (AO) Module 100% Brand New

SKU CC-PAON01

  • Part Number:

    CC-PAON01

  • Manufacturer:

    Honeywell

  • Condition:

    Brand New & in Stock

  • Product Type:

    Analog Output (AO) Module

  • Origin:

    USA

  • Shipping Detail:

    Fedex and UPS etc

  • Warranty:

    12 months

Frequently inquire Together

100% Genuine Stock, 24/7 Service

Inquiry

Honeywell CC-PAON01 Analog Output Module

Configured for analog signal generation in Honeywell Series C control architectures, the Honeywell CC-PAON01 (CC-PAON01 Analog Output Module) provides direct 4-20 mA output control for field instrumentation and final control elements within Experion PKS platforms. The module supports 16 analog output channels, galvanic isolation, output current readback diagnostics, and high-level analog signal transmission through a Series C I/O infrastructure.

Hardware Specifications

Parameter Specification
Model CC-PAON01
Brand Honeywell
Product Type Analog Output Module
Series Honeywell Series C
Origin USA
Operating Temp 0 deg C to +60 deg C
Relative Humidity 5% to 95% RH, non-condensing
Power Consumption Approx. 5.3 W maximum
Supply Voltage 24 VDC nominal
Supply Voltage Range 21.6 VDC to 26.4 VDC
Current Consumption 220 mA maximum
Channel Count 16 channels
Output Signal Range 4-20 mA
Resolution 12-bit
Output Load Up to 750 Ohms at 24 VDC
HART Support Not supported
Accuracy +/-0.1% FSR at 25 deg C
Temperature Drift +/-0.005% FSR/deg C maximum
Refresh Rate 20 ms for all 16 channels
Isolation Type Galvanic isolation
Diagnostics Output current readback monitoring
Protective Coating G3 conformal coating

Galvanic Isolation and 4-20 mA Output Performance

The CC-PAON01 is designed for high-level analog output applications using standard 4-20 mA current-loop technology. Galvanic isolation between field circuits and system electronics helps reduce the transfer of ground-potential differences and electrical disturbances into the control platform.

The module updates all sixteen output channels every 20 ms and incorporates output current readback functionality. Continuous readback monitoring assists in detecting open-loop conditions, wiring abnormalities, and output circuit faults while maintaining closed-loop control accuracy.

Frequently Asked Questions

Q: Does the CC-PAON01 support HART communication?
A: No. The module is specified as a non-HART analog output module.

Q: What analog signal range is provided by the module?
A: The module generates standard 4-20 mA analog output signals.

Q: Is output verification available?
A: Yes. The module includes output current readback diagnostics for monitoring output circuit status and fault conditions.

Field Installation Guidelines

  • De-energize the cabinet before installing or replacing the module.

  • Verify field device load resistance does not exceed the specified limit.

  • Route analog output wiring separately from power cables.

  • Maintain proper shield grounding according to site standards.

  • Confirm channel scaling and loop current values during commissioning.

  • Verify output readback diagnostics after startup.
