InquiryHoneywell CC-PDIS01 Low Voltage Digital Input SOE 24V
The Honeywell CC-PDIS01, also cataloged under part numbers 51405042-175 / 51405042-176, is a 32-channel digital input module designed for Sequence of Events (SOE) recording in Experion PKS Series C and C300 controllers. It provides precise time-stamped event capture for critical process monitoring.
Hardware & Input Specifications
| Parameter | Specification |
|---|---|
| Model | CC-PDIS01 |
| Brand | Honeywell |
| Origin | USA |
| Weight | ~0.35 kg (0.77 lbs) |
| Input Channels | 32 |
| DI Power Voltage Range | 18–30 VDC (Nominal 24 VDC) |
| ON Threshold | ≥13 VDC or ≥3 mA |
| OFF Threshold | ≤5 VDC or ≤1.2 mA |
| Input Impedance | 4.2 kΩ |
| Field Resistance (ON) | 300 Ω @ 15 VDC |
| Field Resistance (OFF) | 30 kΩ @ 30 VDC |
| Isolation | Optical galvanic isolation, 1500 VAC RMS / ±1500 VDC |
Performance & Timing
- SOE Time Resolution: 1 ms (high-accuracy event capture)
-
Channel Scanning Rate:
- Normal Mode: 20 ms
- Fast Mode: 5 ms
- Absolute Delay: 5 ms ±20%
This ensures deterministic monitoring of discrete events, critical for turbine trips, breaker operations, and safety interlocks.
Functional Features
- High-Resolution SOE: Captures millisecond-level event timing for precise sequence analysis.
- Galvanic Isolation: Protects logic circuits from field disturbances.
- Fast Mode Scanning: Enables rapid detection of transient events.
- System Integration: Seamlessly connects with Experion PKS Series C/C300 controllers.
Frequently Asked Questions
Q: What is the primary advantage of SOE capability? A: It provides millisecond-level time stamps for discrete events, enabling root cause analysis in safety-critical systems.
Q: Can the CC-PDIS01 operate in harsh environments? A: Yes, it is designed for industrial-grade operation with optical isolation and robust input thresholds.
Q: How does the module handle fault conditions? A: Fault isolation is achieved through optical galvanic separation, preventing propagation of field disturbances into system logic.
Field Installation Guidelines
- Mount securely in Series C chassis with proper connector alignment.
- Use shielded cabling for input wiring to minimize EMI.
- Maintain separation between low-voltage logic and high-voltage circuits.
- Verify polarity and compliance with 18–30 VDC input range.
- Confirm diagnostic LEDs during commissioning to validate input states.
-
