Honeywell SPXCDXSHXSS Hydrogen Sulfide Sensor

Description

The Honeywell SPXCDXSHXSS is a replacement sensor cartridge for hydrogen sulfide (H₂S) detection, designed for use with the Sensepoint XCD fixed gas detector. It offers reliable performance in hazardous indoor and outdoor environments.

Specifications

• Model: SPXCDXSHXSS

• Sensor Type: Hydrogen Sulfide (H₂S)

• Measurement Range: 0–50 ppm

• Supply Voltage: 16–32 VDC @ 208.3 mA

• Inrush Current: 800 mA @ 24 VDC max

• Output Signal: 4–20 mA (sink or source)

• Communication: RS485, MODBUS RTU

• Operating Temperature: –40°F to +149°F (–40°C to +65°C)

• Conduit Connection: 2 × ¾" NPT

• Enclosure Rating: NEMA 4, IP66

• Housing Material: Epoxy-painted aluminum alloy LM25

• Sensor Material: Stainless steel

• Mounting: Integral plate with 4 × M8 bolt holes

Features

• Remote Sensor Capability: Supports remote mounting up to 30 meters from transmitter for hard-to-reach areas.

• Tri-Color Backlit Display: Provides clear visual status with digits, bar graph, and icons.

• Magnetic Switch Configuration: Enables non-intrusive setup and calibration.

• Auto-Inhibit Mode: Prevents false alarms during maintenance.

• Flexible Output Options: Selectable sink/source 4–20 mA and MODBUS for system integration.

• Rugged Design: Built for explosive atmospheres and harsh industrial environments.

• Minimal Training Required: Intuitive interface reduces setup time and operator error.
