Schneider TM241CE40T Logic Controller

Configured for high-speed motion control and machine automation within the Modicon M241 platform, the Schneider TM241CE40T (TM241CE40T Logic Controller) provides direct physical/electrical execution.

Hardware Specifications

Industrial Control and High-Speed Motion Execution

Modicon M241 controllers execute real-time motion and sequential machine logic in high-performance automation architectures. The TM241CE40T features 8 fast inputs (HSC mode up to 200 kHz) and 4 fast transistor outputs (PTO/PWM up to 100 kHz) for accurate multi-axis positioning and encoder feedback processing. Built-in industrial protocols—including EtherNet/IP Originator/Target, Modbus TCP client/server, and OPC UA server capabilities—allow direct integration with human-machine interfaces (HMIs), variable speed drives, and enterprise SCADA databases over standard Ethernet infrastructure.

Frequently Asked Questions

Q: How many local I/O expansion modules can be added to the TM241CE40T controller?

A: The TM241CE40T supports up to 7 local TM3 expansion modules directly attached to the right side, or up to 14 modules in a remote I/O architecture using TM4/TM3 bus expansion.

Q: What is the maximum load current supported by the transistor outputs?

A: Standard transistor outputs (Q0–Q15) support up to 0.5 A per channel, while fast outputs (Q0–Q3) support up to 0.1 A in high-speed PTO positioning mode. The maximum total current per output common is 2 A.

Field Installation Guidelines

• Mount the controller horizontally onto a standard 35 mm DIN rail (TH35-7.5 or TH35-15) inside a grounded metal control cabinet.

• Connect the 24 VDC main supply to the removable 5.08 mm pitch power terminal block, ensuring correct polarity and proper external fusing.

• Wire high-speed PTO/HSC signal lines using shielded twisted-pair cables under 10 meters in length to eliminate electromagnetic interference.

• Ground all cable shields directly to the cabinet single-point ground bar before terminating discrete wires into the removable I/O terminal blocks.

• Plug the Ethernet network cable into the RJ45 port and verify network activity via the panel green Ethernet activity LED before commissioning via EcoStruxure Machine Expert.
