Yokogawa A1BD5D-05 Digital Terminal Board

Description

The Yokogawa A1BD5D-05 is a digital terminal board designed for use in distributed control systems (DCS), particularly within the CENTUM VP architecture. It supports both single and dual-redundant configurations and provides secure signal interfacing for up to 32 digital channels via DIN rail mounting.

Specifications

• Model Number: A1BD5D-05

• Signal Type: Digital (32-channel × 1)

• Redundancy: Supports single and dual-redundant setups

• Mounting Type: DIN rail compatible

• Suffix Code:

  • 0: Always 0

  • 5: Basic type with no explosion protection

• Cable Compatibility:

  • 600V PVC insulated wire (JIS C3307 / IEC 60227-3)

  • KIV, HIV, VW-1 (UL1015/UL1007)

  • CVV control cables (JIS C3401)

• Dimensions: Approx. standard DIN rail size

• Weight: 0.3 kg (shipping weight)

• Compliance: ISA Standard G3 (optional), RoHS

• Lead Time: Typically 1–2 weeks depending on supplier

Features

• High-Density Wiring: Supports 32 digital signals in compact form

• Redundant Configuration: Enhances system reliability for critical applications

• DIN Rail Mounting: Simplifies installation and maintenance

• Flexible Cable Support: Compatible with multiple industrial-grade wiring standards

• Modular Integration: Works with various Yokogawa terminal boards (e.g., A1BA4D, A1BT4D)

• Application Versatility: Suitable for use with ADV561 and other I/O modules
