1756-IF16 | Allen-Bradley | ControlLogix EtherNet/IP | Analog I/O Modules

Environmental Specifications:

Temperature, Operating

• IEC 60068-2-1 (Test Ae, Operating Cold)
• IEC 60068-2-2 (Test Be, Operating Dry Heat)
• IEC 60068-2-14 (Test Nb, Operating Variation of Temperature)
• 0 °C < Ta < +60 °C (+32 °F < Ta < +140 °F)

Temperature, Surrounding Air, Max

• 60 °C (140 °F)

Temperature, Nonoperating

• IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold)
• IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat)
• IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock)
• -40…+85 °C (-40…+185 °F)

Relative Humidity

• IEC 60068-2-30 (Test Db, Unpackaged Damp Heat)
• 5…95% noncondensing

Vibration

• IEC 60068-2-6 (Test Fc, Operating)
• 2 g @ 10…500 Hz

Shock, Operating

• IEC 60068-2-27 (Test Ea, Unpackaged Shock)
• 30 g

Shock, Nonoperating

• IEC 60068-2-27 (Test Ea, Unpackaged Shock)
• 50 g (30 g)

Emissions IEC 61000-6-4

ESD Immunity

• IEC 61000-4-2
• 6 kV contact discharges
• 8 kV air discharges

Radiated RF Immunity

• IEC 61000-4-3
• 10V/m with 1 kHz sine wave 80% AM from 80…2000 MHz
• 10V/m with 200 Hz 50% Pulse 100% AM @ 900 MHz
• 10V/m with 200 Hz 50% Pulse 100% AM @ 1890 MHz
• 3V/m with 1 kHz sine wave 80% AM from 2000…2700 MHz

EFT/B Immunity

• IEC 61000-4-4
• ±2 kV at 5 kHz on signal ports

Surge Transient Immunity

• IEC 61000-4-5
• ±2 kV line-earth (CM) on shielded ports

Conducted RF Immunity

• IEC 61000-4-6
• 10V rms with 1 kHz sine wave 80% AM from 150 kHz…80 MHz
