Emerson KJ1501X1-BC4 Dual DC Power Supply Module

Description

The Emerson KJ1501X1-BC4 is a dual DC power supply module designed for use in DeltaV™ distributed control systems. Engineered for high reliability in hazardous industrial environments, it delivers stable power to system components while meeting stringent safety and environmental standards.

Specifications

• Input Voltage: 12 VDC at 14.8 A or 24 VDC at 6.1 A
• Output Voltage: – 12 VDC at 13 A (with 12 VDC input) – 12 VDC at 8 A (with 24 VDC input) – 5.1 VDC at 2.0 A – 3.4 VDC at 2.0 A
• Total Output Power: 10.2 W (from +5.1 VDC and +3.4 VDC)
• Operating Temperature: -40°C to +70°C
• Shock Resistance: 10 g, ½ sine wave for 11 ms
• Vibration Resistance: 1 mm peak-to-peak (2–13.2 Hz); 0.7 g (13.2–150 Hz)
• Humidity: 5% to 95% RH, non-condensing
• Contaminant Class: ISA-S71.04 Class G3 (airborne contaminants)
• Certifications: ATEX, IECEx, FM, CSA (Zone 2, Division 2)

Features

• Dual DC Output: Provides multiple voltage levels for powering diverse system components
• Hazardous Area Certified: Approved for use in explosive environments
• Compact & Rugged: Designed for space-constrained control cabinets and harsh conditions
• No Calibration Required: Maintenance-free with no user-serviceable parts
• System Integration: Seamlessly integrates with DeltaV™ systems for reliable operation
• Safe Operation: Must be installed and removed with system power off to ensure safety
