Honeywell 2MLQ-TR2B Digital Output Module

Description

The 2MLQ-TR2B is a 16-point digital output module with photo coupler isolation. It supports DC12/24V loads, offers fast 1 ms switching, and includes built-in fuse protection with LED indication for reliable industrial automation.

Specifications

• Output Points: 16 channels

• Isolation Method: Photo coupler isolation

• Rated Load Voltage: DC12/24V

• Load Voltage Range: DC10.2–26.4V

• Max. Load Current: 0.5A per point, 4A per COM

• Off Leakage Current: ≤ 0.1 mA

• Max. Inrush Current: ≤ 4A / 10 ms

• Voltage Drop (On): ≤ DC0.3V

• Surge Absorber: Zener diode (IEC 61006-6-2 compliant)

• Fuse: 4A × 2 (non-replaceable, fuse cap. 50A), common fuse for entire module

• Fuse Display: LED ON and CPU signal transfer when fuse is burnt out

• Response Time (Off → On): ≤ 1 ms

• Response Time (On → Off): ≤ 1 ms (rated resistive load)

• Common Method: 16 points / 1 COM

• Current Consumption: 70 mA (all points ON)

• External Voltage: DC12/24V ±10% (ripple ≤ 4 Vp-p)

• Power Supply Current: ≤ 10 mA (DC24V connection)

• Operation Indicator: LED ON when output active

• External Connection: 18-point terminal block connector

• Weight: 0.12 kg

Features

• High Density Outputs: 16-point configuration for compact distributed control

• Fast Switching: 1 ms response ensures precise control in automation systems

• Built-in Protection: Non-replaceable fuse with LED and CPU signal for fault indication

• Surge Absorption: Integrated Zener diode for compliance with IEC standards

• Compact & Lightweight: 0.12 kg module with space-saving terminal block design

• Industrial Reliability: Stable performance under DC12/24V supply with low leakage current

• Clear Status Indication: LED output ON display for easy monitoring
